2024 New Product Manta 3.6 10km Mini Rc Plane Dr-one Fpv with Camera Transmitter and Receiver
$740.20
SPECIFICATIONS
Arm thickness: 4mm
Battery: 1100mAh 6S
Bottom plate thickness: 3mm
Brand Name: NoEnName_Null
Camera space: 14~20mm
Motor: Axisflying C224 2750KV
Product name: Fpv Dr-one
Propellers: 3.6inch freestyle props
Stack: Axisflying Argus Mini 35A+F7
Weight: 1085
Wheelbase: 162mm
Products Description
|
2024 New product Manta 3.6 10km mini dr-ones with 4K video camera HD fpv rc GPS
|
|
Specifications
|
||
|
Name:
|
Manta 3.6" Lite
|
|
|
Arm thickness:
|
4mm
|
|
|
Srtucture
|
Squashed X
|
|
|
weight
|
257g
|
|
|
Lens space
|
14-20mm
|
|
|
Stack mounting
|
20mm(M2) &30.5mm(M3)
|
|
|
Bottom plate thickness
|
3mm
|
|
|
VTX mounting
|
20mm&25.5mm(M2)
|
|
|
Top plate thickness
|
2mm
|
|
|
Prop size
|
Max 3.6 inch
|
|
|
Carbon material
|
T700
|
|
|
Motor mounting
|
12*12mm(M2)
|
|
|
Bottom to top distance
|
20mm
|
|
|
Weight
|
108±5
|
|
*Feature
- MANTA 3.6 frame is specially designed for 3.6-inch Freestyle and Cinematic, launched in Squashed X.
- Squashed X design for a flexible flight experience, props are not visible from the FPV camera, more suitable for freestyle with high maneuverability.
- The frame adopts the innovative CNC aluminum structure design with the high-strength carbon plate makes the overall structure very strong, stable and safe.
- Manta3.6 will be equipped with a dedicated Flystack - an Argus mini FC and ESC independently developed and produced by
Axisflying, using BZ121 compass and MPU6000 gyroscope.
- The propellers of Manta3.6 are also customized, available in green and gray.
- It is also compatible with VTX and cameras such as Analog, Link, Walksnail, etc. Free to change and match.
- High performance is the core advantage of Manta3.6. It only takes 0.3 seconds to accelerate from 0-100kph under no-load
condition, and the flight time is more than 8 minutes. In the state of mounting GoPro10, the top speed can still reach 180kph.
- Nylon-sintered side plates are installed on both sides of the FPV to protect the core electronic devices while ensuring that heat dissipation is not affected.
- The power cable can protrude from the front and rear of the FPV, which is convenient for the pilots to adjust the center of gravity of the dr-one by themselves.
- Supportting dual antennas.
- MANTA 3.6 frame is specially designed for 3.6-inch Freestyle and Cinematic, launched in Squashed X.
- Squashed X design for a flexible flight experience, props are not visible from the FPV camera, more suitable for freestyle with high maneuverability.
- The frame adopts the innovative CNC aluminum structure design with the high-strength carbon plate makes the overall structure very strong, stable and safe.
- Manta3.6 will be equipped with a dedicated Flystack - an Argus mini FC and ESC independently developed and produced by
Axisflying, using BZ121 compass and MPU6000 gyroscope.
- The propellers of Manta3.6 are also customized, available in green and gray.
- It is also compatible with VTX and cameras such as Analog, Link, Walksnail, etc. Free to change and match.
- High performance is the core advantage of Manta3.6. It only takes 0.3 seconds to accelerate from 0-100kph under no-load
condition, and the flight time is more than 8 minutes. In the state of mounting GoPro10, the top speed can still reach 180kph.
- Nylon-sintered side plates are installed on both sides of the FPV to protect the core electronic devices while ensuring that heat dissipation is not affected.
- The power cable can protrude from the front and rear of the FPV, which is convenient for the pilots to adjust the center of gravity of the dr-one by themselves.
- Supportting dual antennas.
